 Brushless DC Centrifugal Pump >> TL-B10-B Brushless dc pump


Number:
169562016
Name:
TL-B10-B Brushless dc pump
Spec:
9L 5M
Memo:
For more detail,please feel free contact us!
Class:
Brushless DC Centrifugal Pump

    Product Readme

12V or 24V Mini Brushless DC Pumps (TL-B10)

Feature:
Advanced magnetic driving technology for static-seal,
without any leakage forever
Motor widely voltage designed suitable for battery power
supplying with peak-low voltage damply
Durable permanent magnetic rotor with one-off injection
incorporated impeller in smooth balance
Heavy duty work, can sustain continuous 24 hours work
Special designed high efficiency closed-type impeller
Sustain 100ºC hot water circulation
All wetted materials FDA approved to be safety usage
Low or no maintenance
Blocked protection
Polarity protection
Application:

Water dispenser, Water Coolers
Carbonation, Coffee Maker, Beverage Dispenser
Air-conditioner Drain
Chillers, Cooling Circulation, Beer Brewing Chillers
Home Appliance Boosting
Solar Applications

Specification:

1
Max Flow Rate 7L/MIN ,9L/MIN 12L/MIN
2 Max Static Lift 3M 5 M 8 M
3 Rated Voltage 12V / 24V
4 Impeller Type Closed impeller
5 Motor Type brushless DC motor
6 Liquid Temperature 0-100°C
7 Pump Theory Centrifugal pump
8 Ambient Temperature -10-50°C
9 Media Pure Water
10 Waterproof Class IP42 or Submersible (optional)
11 Use Place Indoor Outdoor
12 Working Voltage Range 6~14V or 12~26V
13 Power Consumption 11~31W
14 Noise Class form 1M 40dB /Max
15 Ideal Life Time 20000 Hours
16 Working Mode Continuous
17 OD of Inle thread nozzles:
G1/2
18 OD of Outlet thread nozzles:
G1/2
19 Power Supply DC power supply, battery, solar powered
20 Protection Functions overload protection
21 Remarks Can't dry-running, not Self-priming

 Parameter

Model
Product Code Max Flow Rate (L/M) Rated Voltage (DC) Current (A) Max Water Head (M) Power (W)
TL-B10-B               thread nozzles: G1/2 TL-B10H-B12-0703 7L 12VDC 0.9 3 11
TL-B10H-B12-0905 9L 12VDC 1.4 5 16.8
TL-B10H-B24-0703 7L 24VDC 0.5 3 12
TL-B10H-B24-0905 9L 24VDC 0.8 5 19.2
TL-B10-B24-1208 12L 24VDC 1.3 8 31.2






TL-B10H/PV-B12-1006 10L 12V (7V~24V) 1.4 6 16.8
TL-B10H/PV-B24-1006 10L 24V (14V~32V) 0.8 6 19.2
Note:   1.pump itself meet: /F,food grade 2. /H type liquid≤100°C, not H normal type liquid ≤70°C    3. /S type can be customized, if submersible liquid should be ≤50°C   4. /PV type can be powered by solar panel directly.


Customers how to choose the pump

1. First determine the voltage, current, water head and flow, diameter size, pump water head is generally the subject of the water does not flow when pumped up to the static head, if a customer requires pumping the water to a certain height and then to maintain a certain water flow, select the desired water head must be higher than the specified pumping height. This specific by the supplier according to the actual conditions. Can refer to lift flow graph.
2. To determine the dimension and form (threaded interface, inlet and outlet orientation, aperture size, etc. )
3. To determine the job requirements (temperature, medium, work time and frequency)
4. To determine the functional requirements (time control, pressure control, flow control, speed, etc. )



 For more detail ,please feel free contact us!
