Highest Performance/Size Ratio
• An Ultra-compact design with small size and light weight, saving installation space
Performs Quieter
• Optimized head, chamber, and flow path reduce noise without compromising performance
Lasts Reliably Longer
• Using the advanced diaphragm elastomer and superior DC motor design sets the highest benchmark for service-free operation that exceeds 3000-15,000 hours
High level of gas tightness
• Thanks to stress-optimised structured diaphragm, newly-designed valves and sealing systems, precise placement of the pump head
Little vibration
• Because of leading edge technologies, top quality bearing, superior dc motor
Uncontaminated flow
• No contamination of the media due to oil-free operation
| Pressure Pump (Item Number) |
Vacuum Pump (Item Number) |
Rated Volatage (VDC) |
No-load Current (A) |
Max Pressure (Kpa) |
Max Vacuum (Kpa) |
Max Flow (L/min) |
| TM30-A12-A01-P12006 | TM30-A12-A01-V7006 | 12 | 0.4 | 120 | 70 | 6 |
| TM30-A24-A01-P12006 | TM30-A24-A01-V7006 | 24 | 0.3 | 120 | 70 | 6 |
Technical data
| Motor | DC motor |
| Structure | Diaphragm Pump |
| Media | Most Gases |
| Material | Head Nylon, Membrane EPDM, Valve EPDM |
| Operating Voltage Range | 12V: 9~14VDC 24V: 18~28VDC |
| Lifetime | 3000 hours |
| Working Mode | Interrupt |
| Work Temperature Rise | <70℃ |
| Customized Support | 5V,PWM, FG, Material: membrane / valve / pump head |
TM30 Series Micro Diaphragm Gas Pump Applications: Industrial Pressure & Vacuum Application, Medical Device & Beauty, Medical Diagnostic Equipment, Printer, Air Quality Sampling Monitors, Printer, Medical Atomizer, Gas or Odor Leak Detectors, Cleaning Industry, Laboratory Technology, Analytical Engineering
Gas Detectors
Ink Printer
Medical Device
Cleaning & Disinfection
Strength:
♦ 16000㎡ modern factory with its own physical property rights, ESD anti-static control dust free workshop,100+ sets of professional imported equipment
♦ 4 major professional and precision laboratories that meet the CNAS national laboratory accreditation standards
♦ More than 60 patents in the micro dc pump industry, strong research and development strength, and master advanced industry technology
Pressure：280Kpa
Vacuum：80Kpa; Flow：16L/min
